Pos 序號 |
Name 名稱 |
Description |
Code
Number 圖號 |
QTY/Axle 每軸數量 |
Remarks 備注 |
| 1 | 400k端蓋 | hub cap | 03.212.29.02.0 | 2 | |
| 2 | 銷 | split pin | 03.084.71.17.0 | 2 | |
| 3 | 鎖緊圈 | locking ring | 03.188.04.08.0 | 2 | |
| 4 | 油環 | ring | 03.010.93.34.0 | 2 | |
| 5 | 油封外圈 | ring | 02.5683.63.00 | 2 | |
| 6 | 墊圈 | thrust washer | 03.370.26.24.0 | 2 | |
| 7 | 彈性擋圈 | locking ring | 02.5606.22.90 | 2 | |
| 8 | 彈性擋圈 | locking ring | 02.5606.60.90 | 2 | |
| 9 | 防塵罩 | seal | 03.120.48.13.0 | 2 | |
| 10 | 油封 | 02.5664.58.00 | 2 | ||
| 11 | 油封座 | 03.370.07.62.0 | 2 | ||
| 12 | 油封座總成 | thrust washer | 05.370.07.65.0 | 2 | |
| 13 | 輪轂（外牙） | hub(10-hole) | 03.272.48.78.0 | 2 | 400k 輪轂10孔 |
| 14 | 軸頭螺母 | castle nut | 03.266.47.03.0 | 2 | |
| 15 | O型環 | 02.5678.00.00 | 2 |
